EX-「」P-「」type（communication）

Inspection of explosive equipment test number T51096

Inquire Now Online Message

Conforming standards:

Inspection of explosive equipment test number T51096

Features:

Used in explosion-proof areas such as petrochemical plants and heavy chemical plants

JP-「」、AP-「」SPD installed

Applications:

Used for information lines such as communication and control cables in explosion-proof areas

Public telephone line

DC and AC power overlap circuits

All lines except unbalanced lines

Multiple lines

Telemeter lines etc

(274C3$B4YBZXZV7Y]IG3

Product type identification:

Model number	Installed SPD	Applications
EX-JP-K3	JP-K3	Dc and Ac power superimposition circuits
EX-AP-K3	AP-K3	Dc and Ac power superimposition circuits
EX-JP-N1	JP-N1	All lines except unbalanced lines.
EX-AP-N1	AP-N1	All lines except unbalanced lines.
EX-JP-N3	JP-NM-4P	Same as type N. Particularly useful for multicircuit, multicircuit circuits.
EX-AP-N3	AP-NM-4P
EX-JP-NM-T4	JP-NM-T4
EX-AP-NE	AP-NE	Same as type N. In particular, circuits that are expected to generate interline voltages
EX-JP-NZ-1	JP-NZ-1
EX-JP-H3	JP-H3	Telemetry line etc.
EX-AP-H3	AP-H3	Telemetry line etc.
EX-JP-E1	JP-E1	ditto However, protection for equipment with high ground voltage but low wire voltage
EX-AP-E1	AP-E1
EX-JP-E1-Y1	JP-E1-Y1	ditto The npulse waveform protects the tail for long waves.
EX-JP-H2-Y1	JP-H2-Y1	elemetry line etc. However the signal polarity of the equipment side is clear, so the voltage between the ground and between the lines Lower equipment protection
EX-JP-K2	JP-K2	Dc and Ac power superimposed circuits
EX-AP-K2	AP-K2	Dc and Ac power superimposed circuits
